Trius-SX814

The Trius-SX814 is a higher resolution version of the very popular H694 camera. It has a similarly high QE and low thermal noise, but offers 9.19 megapixels of resolution. Each pixel is 3.69 x 3.69 uM in size. This very high resolution makes the 814 particularly well suited to the super-fast short focus 'scopes and 'Hyperstar' systems that are now widely in use. The new 'Trius' version adds a triple USB hub and Argon fill to the H814 design.

SX-814-2

Trius rear2

Specification:

Image format - 3388 x 2712 pixels in a 12.5 x 10mm array.

Pixel size - 3.69 x 3.69 uM

QE - Peak (Yellow light) approx. 75%, H-alpha approx. 60%

Well depth - 18,000e

System gain - 0.25e / ADU

Image download time - 7 seconds in 1 x 1 binning mode

Cooling - 2 stage high efficiency Peltier cooler giving approx. -40C temperature reduction

Triple port powered USB hub built-in.

Dry Argon filled CCD chamber.

Power consumption - 1.5 amps max. at 12v DC (universal AC supply provided)

Back focal length 17mm +/-1mm.
